Exclude Internal Traffic IP Address in GA4

Imagine having an e-commerce website through which your company sells its products, and a substantial workforce regularly interacts with the site as part of their roles. At the end of the day, your Google Analytics 4 (GA4) reports will include information about website traffic from both your staff (referred to as 'internal' traffic) and potential customers.

The above setup is not ideal. You target your paid marketing campaigns (Facebook and Google Ads, etc) around potential customers, not your employees. As such, it might be useful to exclude the latter.

Excluding internal traffic in GA4 is a two-step process.

First, we identify internal traffic by instructing GA4 to append a parameter called ‘traffic_type’ with a defined value to events generated by users interacting with the site from specific IP addresses. Then, we create data filters that exclude events with that parameter and value combination. Let’s explore this process in greater detail!

Identifying IP addresses whose traffic should be marked as internal / Setting up traffic rules

I will be using Nuna Baby for this tutorial as they asked us to audit their GA4 setup. I still have not done anything. To demonstrate this, let's generate a test 'page_view' request and examine its details sent to GA4.

The following passage describes how to explore events sent to GA4 using the Developer Tools.

I accessed the Nuna Baby website in my Chrome browser and hit F12 to open the Developer Tools, and then selected the Network tab. With the Developer Tools open, I hit F5 to refresh the page. The Networks tab shows all requests the website makes. I am only interested in requests that are made to GA4 servers. To isolate these requests, we can filter them by entering '/collect?v=2&tid=G-' into the URL filter field. This will help us focus on GA4's data. Here is how it looks:

Screenshot of chrome developer tools networks tab showing filtered requests to GA4 servers

We can then click on one of these remaining requests (that have not been filtered out) and open the Payload tab to reveal what is being sent:

GA4 request details in Chrome DevTools Networks tab, showing query parameters in Payload

Each parameter is a key/value combination. The Developer Tools parse what would otherwise be an incredibly long POST request URL into this table format, where each key is bolded, and the value follows the colon character.

The ‘traffic_type’ parameter, if appended, will appear as ‘tt:.’ As you can see, that parameter does not appear in the above screenshot, so it was not sent with the ‘page_view’ event we generated.

Now, let’s head over to, select our Nuna Baby account, and navigate to a screen that allows us to define internal traffic:

Property > Data Streams > Web > Click on your web stream > Configure tag settings > Show all > Define internal traffic.

Nuna Baby mentioned that they have offices at two locations that can be identified with the following IP addresses:

  • Morgantown, PA :
  • Elverson, PA :

Plus I will want to exclude my own IP address since I plan to keep testing their site quite a bit (as such, I will define three traffic rules in total).

I will click on the ‘Create’ button to create a new internal rule. Here is my traffic rule setup:

Google Analytics: Creating Nuna Baby internal traffic rule

It means that interactions (read ‘events’) with the Nuna Baby website coming from my IP address ( should now have an extra parameter ‘traffic_type’ with a value of ‘internal_alexsb.’

The default ‘internal’ value

It's worth mentioning that the default value for this parameter is 'internal,' and you can retain it as such. That being said, I encourage you to come up with a unique value for each office location that has a unique IP address. Since Nuna Baby has two office locations, each with their own IP address, I will have a total of three traffic rules, each with its own unique ‘traffic_type’ parameter. Here is how those traffic rules look once created:

Screenshot of Google Analytics internal traffic rules for Nuna Baby, displaying the created rules

With the above traffic rules saved, let’s refresh the Nuna Baby homepage one more time and see if we can find that new ‘traffic_type’ parameter as part of the event:

Chrome DevTools: 'traffic_type' parameter in Nuna Baby event

There you have it! The internal traffic rule works. Every event (a user interaction on the Nuna Baby website) coming from my IP address will now include that extra ‘traffic_type’ parameter.

Theoretically, if someone at Nuna Baby’s Elverson office were to visit their site, their events would be tagged with the ‘internal_elverson’ parameter value.

So why not just use the default ‘internal’ parameter value for everyone, you might ask? It is a great question and I will tackle it in a bit.

Creating data filters / Excluding my own traffic

If only there was a way to tell GA4 to not record events that have a specific value of the ‘traffic_type’ parameter …. Fortunately, there is one! Let’s see how that works.

In the same Nuna Baby GA4 account I will head over to:

Property > Data settings > Data filters

Once there, I will create a new data filter by clicking on the ‘Create’ button and selecting the ‘Internal traffic’ type. The other option is ‘Developer traffic’. The difference between the two is described at the very end. Here is my data filter setup:

Data filter setup for Nuna Baby Google Analytics property: creating new data filter for Internal traffic type

The important settings are the ‘Filter operation,’ which I have set to ‘Exclude’ (since my intention is to exclude my own - internal - traffic), and the ‘Parameter value’, which must match the ‘traffic_type’ value we have set in Define internet traffic rules.

Highlighted below are the three data filters I set up:

Screenshot: highlighted new data filters

It is a good idea to be mindful of the data filter names (first column) as those will appear as values of the default ‘Test data field name’ dimension in Exploration reports.

Another thing to keep in mind is that GA4 imposes a limit of 10 data filters per property!

Note that there are three possible filter states: testing, active and inactive. In the ‘Testing’ state, event data is still not filtered out from reports, but all events generated by traffic from listed IP addresses include the ‘traffic_type’ parameter. The testing state allows us to get a feel for the filter before permanently activating it.

Seeing the results in reports

Testing a filter before activation ensures that it successfully filters out traffic from the designated IP addresses. Traffic from filtered IP addresses is added to the "Test data filter name" dimension with the filter name as the value.

To find events triggered by a filtered IP address, you can build a free-form exploration with these settings:

  • Technique: Free form
  • Rows: Test data filter name
  • Values: Event count

A data filter can take between 24 - 36 hours to apply.

Here is how my exploration report looks:

Screenshot of exploration report showing test data filter results and settings in Google Analytics

Hold on, have not we set up rules and filters for the Elverson office? We sure did! Here are a couple of reasons why none of the events had the ‘internal_elverson’ parameter added:

  • Elverson office personnel could be on holiday and still have not visited the site.
  • Or more likely, the IP address referenced in the data filter is incorrect.
Screenshot highlighting IP address referenced in the data filter

While the Elverson record is absent, it's evident that a total of 340,835 events were recorded. Of those events, 415 were attributed to the Morgantown office and 101 events were attributed to my own IP address. So what is that (not set)? In simple terms, it means that these events were fired without the ‘traffic_type’ parameter. They are your real website users (potential customers).

What is the benefit of giving each office location a unique ‘traffic_type’ value? You can set up unique data filters to distinguish between different offices (one data filter per traffic rule), so you can have separate event buckets of internal traffic. If we were to have just one ‘internal’ traffic type value and, as such, just one data filter, the above report would look like this:

  • (not set): 340,319
  • Internal: 516 (415 + 101)

Morgantown and Alex Sb (which is a traffic rule for my IP address) would be merged together and displayed as one bucket called Internal (or whatever the data filter name we were to give it). We would not know that something might be wrong with the Elverson filter. There would not be away to distinguish one internal traffic source (Elverson) from the others (Alex Sb and Morgantown). Hopefully, it makes sense. Also, if these filters were immediately activated (without first running them in the Test mode), we would not be able to see them in the Exploration reports.

Activating filters

Another advantage of using multiple filters, as opposed to a single generic filter, is the ability to selectively activate those proven to be effective:

Activation of newly created data filters: changing state from Testing to Active in the data filters menu

I will go ahead and change their state from Testing to Active. You do this by clicking on the Activate link of the three-dotted menu.

With the active filter, the Developer Tools still shows the ‘traffic_type’ parameter appended as before. Yet, the event is no longer coming through in the DebugView, as if the event was not taking place:

Screenshot: Absence of event in Debug Device

It means we can continue testing the GA4 event setup using the Developer Tools, but the DebugView feature of GA4 is no longer available for troubleshooting. ‘What a bummer,’ you will say. Can’t we have the best of both worlds? And yes, we can! Being a tracking specialist, my role is to debug GA4 issues. And it is essential that I have access to the DebugView feature. At the time of creating our data filters, we had to choose between the two types: internal and developer:

Google Analytics: Selecting 'Developer traffic' filter type

Since I tackle tracking issues and want to continue using the DebugView, I should have selected the ‘Developer traffic’ type. And that’s the difference between the two! To remedy the setup, I removed the ‘Alex Sb’ traffic rule, removed the ‘Alex Sb’ data filter, and created a new data filter to exclude developer traffic:

New data filter named 'Filter out developer traffic' and setting it to Testing mode

I gave it the name ‘Filter out developer traffic,’ and set it to run in the Testing mode for now. Every time I explore the site in debug mode, GA4 will exclude my event data from the final reports. The ‘traffic_type’ event will no longer be appended to events from my IP address, but I will continue to be able to use the DebugView feature. The best of both worlds, that is!

In conclusion, by meticulously identifying internal traffic, setting up tailored traffic rules, and employing data filters, you can ensure that your Google Analytics 4 reports accurately reflect customer interactions and provide valuable insights for optimizing your marketing strategies.
